Jewellery Label

Label Dimension (mm) : 71 x 36 x 0.2 mm
IC Type : NXP Ucode 9
Read Range from a : Up to 4 Meter (Fixed Reader) / Up to 2 Meter (Handheld Reader)
Operating Temperature : -40 °C to +85 °C

Download Datasheet Enquire Now
Category:

Description

Label Dimension (mm) : 71 x 36 x 0.2 mm
Surface Material : PET
Frequency : 860-960 MHz
IC Type : NXP Ucode 9
Protocol : EPC Class 1 Gen 2; ISO 18000-6C protocol compliant
EPC Memory : 96 bit
Data retention of IC : 50 Years
Write endurance of IC : 100,000 cycles
Operating Temperature : -40 °C to +85 °C
Storage Temperature : -40 °C to +85 °C
Application : Ornament Identification, Jewellery Tracking, Diamond Tracking.
Options : Encoding and Printing Barcode/QR Code/LOGO etc.
